QNBBM Lithium Battery Equalizer 8S 24V Balancer Lifepo4 LTO NCM LMO 18650 DIY Pack Voltage Balancing
- 2022-12-12 -
Product Introduction
QNBBM Lithium Battery Equalizer 8S 24V Balancer Lifepo4 LTO NCM LMO 18650 DIY Pack Voltage Balancing
eep the voltage difference of each cell within 5-10mv.
Extend the battery span life 2-3times.Without capacity & voltage & battery type limitation .
Your best battery pack protector/battery spanlife extender. Perfect combination with passive bms.
Let’s Save cost from now, click here send an inquiry
Product Parameters
|
Name
|
QNBBM Lithium Battery Equalizer 8S 24V Balancer Lifepo4 LTO NCM LMO 18650 DIY Pack Voltage Balancing
|
|
Battery capacity limited
|
Unlimited
|
|
Battery count limited
|
2S~unlimited, At least balance 2 cells
|
|
Battery type limited
|
Battery:Lifepo4,LiMnO4 etc,
AGM,Gel,Flooded battery and so on
|
|
Working voltage
|
1.8V~5V (2V lead acid battery and lithium battery
4V~9V (6V lead acid battery)
9V~15V (12V lead acid/Li battery)
|
|
Power consumption
|
9V~15V (12V lead acid/Li battery)
|
|
Voltage difference VS Balance current
|
300mV-1A; 1V-3A
|
|
Voltage difference after the balancer
|
<10mv
<30mv(12V lead acid)
|
|
Working efficiency when balance current is 1A
|
>94%
|
|
Working temperature
|
-40~+80C
|
|
Storage temperature
|
-40~+100C
|
|
BMS limited
|
can work with BMS,Or can work independently
|
