CATL Lifepo4 3.2V 202Ah Battery Cell 1C-3C High Power Discharge Brand New Grade A Battery
- 2022-12-14 -
CATL 3.2V rated Lifepo4 202Ah lithium batteries 3.2V lifepo4 200ah battery for ev car, home storage and solar energy
|
Normal capacity
|
202ah
|
|
Normal voltage
|
3.2V
|
|
Charging voltage
|
3.65 ±0.05 V
|
|
Internal resistance
|
≤0.5mΩ(AC Impedance, 1000 Hz)
|
|
Discharge ending voltage
|
2.6 ±0.05 V
|
|
Standard charging current
|
0.5C
|
|
Standard discharge current
|
1.0C
|
|
Max charge current
|
1.0C
|
|
Max discharge current
|
3.0C
|
|
Weight
|
400±100g
|
|
Cell dimensions |
Thickness: 55mm
Width: 175 mm Height: 205mm |
